ResQguard™- RG3000
SKU: N/A
ResQguard™- RG3000
Portable davit arm is designed for manhole and confined space entry/rescue applications. A variety of winches and/ or fall arrest blocks can be mounted as required. It is ideal for providing portable, secure overhead anchorage in large confined areas such as manholes, storage tanks, etc. The inbuilt enclosure provides storage for PPE and the castor wheels allow easy transportation of the system.
- Description
- Product Specification
- Downloads
- Applications
- Industries
Description
Confined Space Rescue – Modular Davit Arm with inbuilt Storage Box
Product Specification
| Net Weight | 130 kg |
| Overall Height | 2.4 meter (7.87 feet) |
| Telescopic Reach | 70 cm to 100 cm (27.5 inch to 39 inch) |
| Vertical Height Range | 196 cm to 210 cm (77 inch to 83 inch) |
| Base Width Range | 155 cm to 190 cm (61 inch to 75 inch) |
| Material of Construction | Aluminum 6063 – T6 (Sections) & Zinc Plated MS (studs & Pins) |
| Product Color | Powder Coated Yellow & Black Combination |
| Anchorage Capacity | 22 KN |
| Load Capacity | 200 Kg |
| Min. Breaking Strength | 14 KN |
| Install type | Portable |
| Operating Temperature | -40° C to +60° C |
| Recommended Industry | Construction, General Industrial, Mining, Oil & Gas, Transportation, Utilities |
Applications
Tanks
Vessels
Drainage system
Sewerage system
Pharma industry
Chemical plants
Industries
Construction
Mining
Oil & Gas
General Industrial
Transportation
